Main Specifications
Model | ECOSYS FS-1025MFP | ||
Type | Desktop | ||
Writing Method | Semiconductor Laser | ||
Main Function | Copy, Print, Scan | ||
Warm Up Time (from Power On) | 28 sec or less | ||
CPU | ARM926EJ 390MHz | ||
Memory | Standard 64MB RAM | ||
Paper Capacity (80 g/m²) | 250 sheets (Cassette) + 1 sheet (Manual Feed Tray) | ||
Paper Size – Front Cassette / Manual Feed Tray | A4, A5, A6, B5, Letter, Legal, Custom (70 x 148 to 216 x 356mm) | ||
Paper Weight – Front Cassette / Manual Feed Tray | 60 – 220 g/m² | ||
Output Capacity | Max. 100 sheets face-down | ||
Duplex | Auto | ||
Max. Monthly Duty Cycle | 20,000 pages | ||
Power Source | AC 220 – 240 V, 50/60 Hz | ||
Power Consumption (Standard configuration) | Print Mode | 348W | |
Stand-by Mode | 7W | ||
Operation Environment | Temperature | 10℃ – 32.5℃ | |
Humidity | 15 to 80% RH | ||
Noise(ISO7779/ ISO9296) | Print Mode | 50dB(A) | |
Stand-by Mode | 29dB(A) | ||
Dimension (W x D x H) (Main Unit) | 390x361x362 | ||
Weight (Main Unit) | 10.0 kg |
Print Functions
Model | ECOSYS FS-1025MFP | |
Print Speed (A4) | 25 ppm | |
First Print Out Time | 7.5 sec or less | |
Resolution | Fast 1200, 600dpi | |
Emulations | Host-based | |
Operating System Supported | Microsoft Windows XP/ Vista/ 7, Window Server 2003/2008, Mac OS x (Print only) | |
Interface | High Speed USB2.0 10/100 Base-TX |
Copy Functions
Model | ECOSYS FS-1025MFP | ||
Print Speed (A4) | 25 ppm | ||
Copy Size | Max. Legal | ||
First Copy Time (Mono/Color) | 11 sec or less | ||
Resolution | 600 x 600 dpi | ||
Zoom Ratio | Manual | 25% – 400% (1% per Step) | |
Pre-defined | Reductions / 5 Enlargements | ||
Multiple Copy | 1 – 99 |
Scan Functions
Model | ECOSYS FS-1020MFP | ECOSYS FS-1025MFP | |
Scan Speed (A4) | A4 300dpi | 20 ppm | |
Original Size | Max. Legal | ||
Resolution | 600dpi, 400dpi, 300dpi, 200dpi | ||
Image Type Mode | Text, Photo, Text + Photo | ||
File Format | TIFF, PDF, JPEG, BMP, PNG | ||
Transmission Type | Scan to Folder; Scan to Email; TWAIN/WIA (Send to PC connected through USB device) | ||
Fax Functions (ECOSYS FS-1120MFP / ECOSYS FS-1125MFP Only)
Model | ECOSYS FS-1020MFP | ECOSYS FS-1025MFP | |
Transmission Method | SuperG3 (Max. 33.6 kbps) | ||
Fax Scanning Density | |||
Superfine | |||
Halftone | |||
Compression Method | MMR, MR, MH | ||
One Touch Dial | Up to 3 addresses | ||
Group Dial | Up to 20 addresses | ||
Address Book | Up to 100 addresses |
